Featuring:

• Auto thick/thin sectioning from 5-4999nm with 4 memory storage channels
• Compact two piece design with advanced antivibration system
• Separate control unit for maximum flexibility and ease of use
• Built-in hand rests
• Modern one piece laminated cover
• PowerTome, high stability, zero backlash, cutting arm drive system
• High precision micrometer knife stage
• Ergonomic stereomicroscope system with constant radial focus eucentric tilt control
• Supplied complete with the following:
• Specimen orientation mount (formerly arc segment mount)
• Stemi 2000 stereomicroscope 7.7:1 zoom range, 6.5X to 50X magnification with 10X WF (23mm) eyepieces
• Self locking Positrac(TM) knife stage
• One universal transilluminated specimen holder with wrench
• One 7mm flat specimen transilluminated holder
• LED backlighting and specimen transillumination with brightness control
• Overhead diffused light
• Glass knife support
• Wooden accessory box
• Trimming block and post
• Stereomicroscope mounted breath shield
• Stage mounted air draft shield
• Control unit
• Power cord
• Interconnect cables
• Dust cover
• Spare lamps & fuses
• Instruction manual
• Wrenches

Specifications

• 100/120/220/240 Vac 50/60 Hz power input
• Shipping Dimensions: One pallet base, tri-wall crate, 840mm x 560mm x 635mm plus one accessory carton, 610mm x 610mm x 610mm
• Net Weight: 33 kg (72 lbs.) Gross Weight: 74 kg (164 lbs)
